Clamping force (Ton)	150KN / 150T
	Daylinght Distance (mm)	600
Clamping Unit	Main RAM Stroke (mm)	450
	Heating platen size (mm)	600 x 700
	Heating load (Kw) X 2	9

	Oil tank capacity (Ltr)	300
Hydraulic unit	Working pressure (Bar)	210
	Motor rating (Kw)	5.5

	Transfer pressure	1500KG / Sq.Cm
Transfer Unit	Transfer Volume (CCM)	2000 GM
	Number of Nozzle	4

	BOT & TOP Ejector	5T x 250mm
Optional features	Outside Ejector	NA
	Outside platen slide	NA
